Fluke 5320A Multifunction Electrical Tester Kit

The Fluke 5320A is a premium multifunction electrical tester kit designed for electrical engineers, technicians, and serious DIY enthusiasts who demand precision, reliability, and efficiency in one comprehensive toolset. Built with Fluke renowned engineering standards, this kit combines multiple testing functions into a single, portable, and rugged unit.

Key Features:

• Multifunction Testing: Measures voltage, current, resistance, continuity, insulation, and more, reducing the need for multiple devices.

• High Accuracy: Provides precise readings with minimal error, ensuring safe and reliable testing in industrial, commercial, and residential environments.

• User-Friendly Interface: Intuitive controls, clear display, and easy-to-read measurements make complex testing simple.

• Durable Design: Engineered to withstand rough environments with shock-resistant casing and high-quality components.

• Comprehensive Kit: Includes all essential accessories and leads for immediate use, making it ready for fieldwork or lab testing.

• Data Logging & Connectivity (if applicable): Some versions allow you to log measurements and transfer data for analysis and reporting.

Applications:
The Fluke 5320A is ideal for troubleshooting electrical circuits, preventive maintenance, quality assurance testing, and educational or laboratory use. It is suitable for electricians, maintenance teams, engineers, and technicians who need a versatile, reliable, and portable solution for all types of electrical testing.

Why Choose the Fluke 5320A:
With this kit, you get a single tool that replaces multiple meters and testers, saving time, reducing errors, and increasing safety. Fluke reputation for precision and durability ensures your investment delivers professional-grade results every time.

In the Box:

• Fluke 5320A Multifunction Electrical Tester

• Test leads and probes

• Carrying case

• User manual and documentation

• Additional accessories for specific testing tasks

Experience the ultimate combination of versatility, accuracy, and reliability with the Fluke 5320A Multifunction Electrical Tester Kit – the all-in-one solution for modern electrical testing.

Technical Specifications

Resistance & Voltage Source

• Precision Low Resistance Source:

  • Range: 100 mΩ – 10 kΩ

  • Resolution: 3.5 digits (continuous)

  • Max Current: 5 mA – 400 mA

  • Accuracy (1 year): ±0.2 %

• High Resistance / High Voltage Source:

  • Range: 10 kΩ – 100 GΩ

  • Max Voltage: 55 Vpk – 1575 Vpk

  • Accuracy (1 year): ±0.2 %

• Resistance Multiplier Adapter:

  • Resistance: 350 MΩ – 10 TΩ

  • Test Voltage Max: 5 500 V dc

Current Testing & Compensation

• High Current Source:

  • Ranges: 25 mΩ – 1.8 kΩ (16 values)

  • Continuous Current: 0.025 A – 30 A

  • Short-term Current: 0.15 A – 40 A

• Loop Impedance Compensation:

  • Scan Mode: 0 – 10 Ω

  • Active Comp Mode: 0 – 2 Ω

Leakage Current & RCD / GFCI Testing

• Leakage Current Source: 0.1 mA – 30 mA (10 µA resolution)

• Residual Current Device (RCD/GFCI):

  • Trip Current: 3 mA – 3000 mA

  • Trip Time: 10 ms – 5000 ms

Multimeter & Measurement Modes

• Built-in Multimeter:

  • Voltage: 0 – 1100 V ac/dc

  • Current: 0 – 30 A ac/dc

  • Resolution: 4.5 digits

• Hipot / Leakage Testing:

  • Leakage Current: 0 – 300 mA

  • Timer: 0.1 – 999 s

Optional Accessories

• 10 kV Divider / Adapter – for high voltage measurements up to 10 kV

• 40 kV Probe – for extreme measurements up to 40 kV (optional)

• Variants:

  • 5320A/40 (with 40 kV probe)

  • 5320A/VLC (with 600 V source & active loop compensation)

  • 5320A/VLC/40 (combined features above)

General & Physical Specifications

• Dimensions: 450 × 480 × 170 mm

• Weight: approx. 18 kg

• Power Supply: 115/230 V ac ± 10 % (50/60 Hz)

• Power Consumption: Max 150 VA

• Operating Environment:

  • Temperature: 18 °C – 28 °C

  • Storage: ‑20 °C – 70 °C

  • Operating Altitude: up to 3 050 m

• Safety Standards: Class I according to EN61010‑1
